The Blackmagic StudioBridge 100G is a 1 rack unit IP video bridge that connects one or two high bandwidth 100GbE camera or converter streams into a redundant 100G broadcast backbone, built for productions that have a smaller number of very high bandwidth sources rather than a fleet of 10G devices.
Two 100GbE QSFP28 inputs accept one combined stream or two independent streams totaling under 100Gb/s, with SMPTE ST 2022-7 redundancy carried through to 2 100GbE outputs. Full 2110-20/-21/-30/-40 compliance, dual IEC power inputs and a dedicated 1GbE NMOS control port keep the bridge compatible with existing IP broadcast infrastructure.
Highlights
| Bridges one or two 100GbE SMPTE 2110 streams into a redundant 100G backbone | |
| SMPTE ST 2022-7 redundancy carried through to dual 100GbE outputs | |
| Dual IEC power inputs for redundancy | |
| Compact 1 rack unit footprint |
- Product Identifiers -
MPN: CONVNVIPR/SBD100X2EAN: 9338716010565
- Product Specifications -
Inputs and Outputs
| 100GbE Inputs | 2 x QSFP28 |
| 100GbE Outputs | 2 x QSFP28 |
| Channels | 1 or 2 streams, up to 4K60 each |
| Embedded Audio | 16 channels per stream |
Networking
| Redundancy | SMPTE ST 2022-7 on the outputs |
| Standards | SMPTE 2110-20, -21, -30, -40 |
| Accessory Ports | 2 x 10G RJ45, 2 x SFP optical fiber |
| Control Port | 1 x 1G RJ45 for NMOS control and configuration |
| Setup | USB-C for local setup and firmware updates |
Control and Physical
| Display | 2.2 inch front LCD with control knob and buttons |
| Audio Monitoring | Built in speaker and 1/4 inch headphone output |
| Color | 10-bit 4:2:2, Rec.709 and Rec.2020 |
| Power | Dual internal IEC C14 AC inputs |
| Rack Size | 1 rack unit, 19 x 8.6 x 1.7 in |
| Warranty | 1 year limited manufacturer warranty |
