The Blackmagic Camera ProDock turns a compatible iPhone into a professional production camera, adding genlock, timecode, balanced audio and external SSD recording through the Blackmagic Camera app, with a single USB-C cable connecting the dock to the phone.
A full size HDMI 2.1 output feeds a monitor or switcher, a BNC input accepts Tri-Sync or Black Burst genlock, and a second BNC input brings in external timecode, with the 3.5mm audio input able to carry timecode as well. Two USB 3.2 ports record straight to external SSDs while a third USB 2.0 port runs accessories, and a locking 12 to 15V DC barrel input powers the whole rig along with the phone and any connected USB-C gear.
Highlights
| Adds genlock, timecode and professional I/O to compatible iPhone models | |
| Full size HDMI 2.1 output plus BNC genlock and timecode inputs | |
| Two USB 3.2 ports for recording directly to external SSDs | |
| Single USB-C connection to the phone, powered by an external DC supply |
- Product Identifiers -
MPN: CINTDOCKPROEAN: 9338716010107
- Product Specifications -
Compatibility
| Phones | iPhone 15 Pro, 15 Pro Max, 16 Pro, 16 Pro Max, 17 Pro, 17 Pro Max |
| Software | Requires iOS 26 or later and the Blackmagic Camera app |
| Genlock Support | iPhone 17 Pro and 17 Pro Max only |
Video and Sync
| HDMI Out | 1 x full size HDMI 2.1 |
| Genlock In | 1 x BNC, Tri-Sync or Black Burst |
| Timecode In | 1 x BNC, plus 3.5mm audio input |
Audio and Storage
| Audio In | 1 x 3.5mm stereo |
| Audio Out | 1 x 3.5mm stereo headphone |
| Recording | 2 x USB 3.2 ports for external SSD recording |
| Accessory Port | 1 x USB 2.0 |
Power and Physical
| Power Input | Locking 5.5mm barrel, 12 to 15V DC; 60W supply included with 7 international plug adapters |
| USB-C Output | 5V at up to 1.5A per port |
| Mounting | 1/4-20 locking points, top and bottom |
| Dimensions | 1.0 x 6.42 x 2.60 in |
| Weight | 9.52 oz |
| Warranty | 1 year limited manufacturer warranty |
