The Blackmagic DeckLink IP 100G is a PCIe Generation 4 capture and playback card that connects a workstation directly to a SMPTE 2110 broadcast network, capturing and outputting up to 8 simultaneous channels of HD, Ultra HD or DCI 4K video at up to 120 fps.
Two 100Gb/s QSFP28 Ethernet ports give dual network redundancy under SMPTE ST 2022-7, with full ST 2110-20, -21, -30 and -40 compliance, PTP timing and NMOS IS-04/IS-05 discovery so the card drops straight into an existing IP broadcast infrastructure. GPUDirect RDMA support moves captured frames straight into GPU memory, cutting latency for real time graphics, virtual production and AI pipelines.
The card works with DaVinci Resolve, Final Cut Pro, Premiere Pro and Avid Media Composer on Windows, macOS and Linux, and ships with Media Express, Disk Speed Test and the Blackmagic Desktop Video Utility, backed by a 3 year warranty.
Highlights
| Up to 8 simultaneous channels of HD, Ultra HD or DCI 4K capture and playback | |
| Dual 100Gb/s QSFP28 ports with SMPTE ST 2022-7 network redundancy | |
| GPUDirect RDMA moves frames directly into GPU memory for lower latency | |
| 3 year limited manufacturer warranty |
- Product Identifiers -
MPN: BDLKIPHIP/100GEAN: 9338716009996
- Product Specifications -
Capture and Playback
| Channels | Up to 8 simultaneous |
| Formats | HD, UHD 4K, DCI 4K up to 120 fps |
| Color | 8/10/12-bit RGB 4:4:4, 8/10-bit YUV 4:2:2, Rec.601/709/2020, HLG and PQ HDR metadata |
Networking
| IP Connections | 2 x 100Gb/s QSFP28 |
| Standards | SMPTE 2110-20, -21, -30, -40; SMPTE 2022-7 redundancy |
| Timing | PTP (IEEE 1588-2008); NMOS IS-04, IS-05 |
| GPU Acceleration | GPUDirect RDMA support |
Card and System
| Card Type | PCIe Gen 4, x8 lane, fits x8/x16 slots |
| Power | 6 pin auxiliary power connector required; built in active cooling |
| Operating Systems | Windows 10/11, macOS 14 or later, Linux |
| Included Software | Media Express, DaVinci Resolve, Disk Speed Test, Livekey, Blackmagic Desktop Video Utility |
| Warranty | 3 year limited manufacturer warranty |
