The Blackmagic StudioBridge 10G PWR is a 2 rack unit IP video bridge that gathers up to 8 separate 10GbE SMPTE 2110 camera or converter streams and combines them onto 2 redundant 100GbE outputs, built for productions that have a fleet of 10G devices to bring into a 100G broadcast backbone.
Each of the 8 RJ45 10GbE inputs also delivers up to 90W of 802.3bt PoE power, so cameras and converters out at the edge of a venue can run without their own separate power supply. SMPTE 2022-7 redundancy on the 100GbE outputs, full 2110-20/-21/-30/-40 compliance and a dedicated 1GbE NMOS control port keep the bridge compatible with existing IP broadcast infrastructure.
Highlights
| Combines up to 8 separate 10GbE SMPTE 2110 streams onto 2 redundant 100GbE outputs | |
| Each of the 8 10GbE inputs delivers up to 90W of 802.3bt PoE power | |
| SMPTE ST 2022-7 redundancy on the 100GbE outputs | |
| Dual IEC AC inputs for power redundancy |
- Product Identifiers -
MPN: CONVNVIPR/SBB10X8PEAN: 9338716010572
- Product Specifications -
Inputs and Outputs
| 10GbE Inputs | 8 x RJ45, each up to 4K60 10-bit video |
| 100GbE Outputs | 2 x QSFP28 |
| PoE | Up to 90W 802.3bt PoE per 10GbE input |
| Embedded Audio | 16 channels per input stream |
Networking
| Redundancy | SMPTE ST 2022-7 on the 100GbE outputs |
| Standards | SMPTE 2110-20, -21, -30, -40 |
| Control Port | 1 x 1GbE RJ45 for NMOS control and configuration |
| Setup | USB-C for local setup and firmware updates |
Control and Physical
| Display | 2.2 inch front LCD with control knob and buttons |
| Audio Monitoring | Built in speaker and headphone output |
| Color | 10-bit 4:2:2, Rec.709 and Rec.2020 |
| Power | Dual internal IEC AC inputs |
| Rack Size | 2 rack units |
| Warranty | 1 year limited manufacturer warranty |
