The Blackmagic UpDownCross 100G is a 1 rack unit standards converter that converts up to 8 independent channels of SD, HD or Ultra HD video to any other standard simultaneously, over a native SMPTE 2110 100G Ethernet connection, built for facilities bringing a mix of legacy and modern formats into a single IP workflow.
Two 100G QSFP28 ports carry SMPTE ST 2022-7 redundant delivery across two separate 2110 networks, with each stream embedding 16 channels of audio, full PTP timing and NMOS IS-04/IS-05 discovery and control. Dual redundant AC power supplies and a separate 1G control port round out a design meant to run unattended in anything from a mobile rack to a full broadcast station.
Highlights
| Converts up to 8 channels of SD, HD or Ultra HD simultaneously, in any direction | |
| Native SMPTE 2110 over dual 100G Ethernet with ST 2022-7 redundancy | |
| 16 channels of embedded audio per stream | |
| Dual redundant AC power supplies for unattended operation |
- Product Identifiers -
MPN: CONVNVIPJ/STG/100GEAN: 9338716010596
- Product Specifications -
Conversion
| Channels | 8 independent, converting simultaneously |
| Conversion Types | Up, down and cross conversion |
| Formats | SD (525i59.94, 625i50), HD (720p to 1080p60, PsF), UHD to 2160p60 |
Networking
| 100G Connections | 2 x 100G QSFP28 |
| Redundancy | SMPTE ST 2022-7 across two 2110 networks |
| Embedded Audio | 16 channels per 2110 stream |
| Timing and Control | PTP (IEEE 1588-2008, ST 2059-1/2); NMOS IS-04, IS-05, BCP-002-01, BCP-004-01 |
| Control Port | 1 x 1G RJ45 for NMOS control, configuration and firmware |
Power and Physical
| Power Supply | 2 x redundant internal AC |
| Rack Size | 1 rack unit, 19 x 8.58 x 1.74 in |
| Warranty | 1 year limited manufacturer warranty |
