The Blackmagic UltraStudio Mini Recorder 12G is a Thunderbolt 4 capture device built for bringing a single 12G-SDI or HDMI source into a computer at up to Ultra HD 4K or DCI 4K, with an SDI loop output so a monitor or router downstream still sees the same feed.
The device is powered over its Thunderbolt cable and works with the same broad codec and software list as Blackmagic's desktop cards, covering DaVinci Resolve, Wirecast, vMix, OBS and most other professional capture, editing and streaming software for live production and post work alike.
Highlights
| Captures a single 12G-SDI or HDMI source up to Ultra HD 4K | |
| SDI loop output keeps a downstream monitor or router in the signal path | |
| Thunderbolt 4 connection, powered over the cable | |
| Works with DaVinci Resolve, Wirecast, vMix and OBS |
- Product Identifiers -
MPN: BDLKULSDZMINREC12GEAN: 9338716010428
- Product Specifications -
Video Inputs
| SDI In | 1 x 12G-SDI, with loop output |
| HDMI In | 1 x HDMI 2.0 |
| Formats | HD to 1080p60, UHD to 2160p60, DCI 4K to 4Kp60 |
| Color | 8/10/12-bit RGB 4:4:4 to 2160p30; 8/10-bit YUV 4:2:2 all standards |
| HDR | Static metadata, HLG and PQ |
Audio
| SDI Audio | 16 channels embedded in |
| HDMI Audio | 8 channels embedded in |
Connectivity and Software
| Computer Interface | Thunderbolt 4 |
| Power | Powered over the Thunderbolt cable, 15W |
| Operating Systems | macOS 15 Sequoia or later, Windows 10/11 64-bit, Linux |
| Included Software | Media Express, LiveKey, Desktop Video Utility |
| Compatible Applications | DaVinci Resolve, Wirecast, vMix, OBS |
Physical and Environment
| Operating Temperature | 5 to 40 deg C |
| Humidity | 0 to 90 percent, non-condensing |
| Warranty | 1 year limited manufacturer warranty |
