The Blackmagic UltraStudio Express Monitor 3G is a pocket sized playback device that outputs a single edit or graphics timeline to 3G-SDI and HDMI simultaneously over one USB-C cable, built for editors who need a broadcast reference monitor without a desktop card or separate power supply.
Like the Recorder model, the Monitor is entirely bus powered over a USB4 or Thunderbolt 4 port, outputting up to 1080p60 in 10-bit YUV or RGB with 16 channels of embedded SDI audio and 8 channels over HDMI. It uses the same DeckLink API as Blackmagic's desktop cards, so it works directly with DaVinci Resolve, Premiere Pro, Media Composer and most other professional video and audio software for client monitoring and confidence checks.
Highlights
| Outputs a single timeline to 3G-SDI and HDMI simultaneously | |
| Fully bus powered, no separate power supply needed | |
| Up to 1080p60 in 10-bit YUV or RGB | |
| Works directly with DaVinci Resolve, Premiere Pro and Media Composer |
- Product Identifiers -
MPN: BDLKULSDMBEXMON3GEAN: 9338716010862
- Product Specifications -
Video I/O
| SDI Out | 1 x 10-bit SD/HD switchable, 270Mb/1.5G/3G |
| HDMI Out | 1 x HDMI 2.0 Type A |
| Formats | SD, HD to 1080p60, 2K DCI to 2Kp60 |
| Color | 8/10/12-bit RGB 4:4:4 to 1080p30 SDI; 8/10-bit YUV 4:2:2 all standards |
Audio
| SDI Audio | 16 channels embedded |
| HDMI Audio | 8 channels embedded |
| Sampling | 48kHz, 24-bit |
| Metadata | RP 188/SMPTE 12M-2 timecode output over SDI |
Connectivity and Software
| Computer Interface | 1 x USB-C, USB 40Gbps, USB4 or Thunderbolt 4 |
| Power | Bus powered over USB-C |
| Codecs | ProRes, DNxHR/DNxHD, uncompressed 8/10-bit 4:2:2 and 10-bit 4:4:4 |
| Included Software | Media Express, Disk Speed Test, LiveKey, Desktop Video Utility |
Physical
| Dimensions | 3.62 x 1.77 x 0.09 in |
| Weight | 5.57 oz |
| Operating Temperature | 32 to 104 deg F |
| Warranty | 1 year limited manufacturer warranty |
