ATTO FastFrame SmartNICs deliver fourth-generation Ethernet performance built for the most demanding storage and data center environments. Designed for line speeds up to 100GbE and engineered for industry-low latency as low as 1 microsecond, FastFrame adapters provide a scalable Ethernet foundation from the core of the data center to the edge. Whether you are supporting high-bandwidth IT workloads or performance-sensitive media workflows, FastFrame SmartNICs are built to keep data moving smoothly, efficiently, and reliably.
FastFrame SmartNICs are especially well suited for modern networks that must handle large volumes of unstructured data. These adapters support media and entertainment workflows such as video post-production, finishing, imaging, archiving, and workgroup file sharing. They are also an excellent fit for IT deployments including data analytics, high-performance computing clusters, hyperconverged servers, AI/ML/DL environments, and unstructured data solutions. This makes FastFrame a practical choice for organizations that want a single adapter family capable of supporting diverse workloads across multiple departments.
ATTO engineers FastFrame SmartNICs with end-to-end Quality of Service and congestion control built into the product. This helps reduce network congestion and maintain consistent throughput even in complex ecosystems where large storage transfers can overwhelm less capable adapters. With RDMA over Converged Ethernet support, FastFrame reduces CPU utilization and enables low-latency transfers for Linux and Windows systems. Combined with hardware and software offload engines, these capabilities help accelerate data movement while minimizing CPU overhead.
FastFrame SmartNICs are designed to simplify deployment and ongoing management. ATTO360 Networking provides tuning profiles for performance optimization, including partner-specific storage profiles. ATTOview monitoring analyzes thousands of metrics in real time and point-in-time using a time series database, while an advanced diagnostics engine identifies bottlenecks and offers direct guidance for resolving connection issues. ATTO Ethernet Suite further streamlines setup by loading drivers, ATTO360, and required dependencies in a single package for Windows and Linux.
For high-resolution video workflows, FastFrame SmartNICs address bandwidth limitations that often prevent competing NICs from reliably supporting 8K. By using RoCE to free up the full pipeline, FastFrame provides the bandwidth needed for multiple streams of raw 8K and 4K video. With multiple models supporting Ethernet standards from 10GbE to 100GbE and connector options including SFP+, RJ45, SFP28, QSFP+, and QSFP28, FastFrame SmartNICs deliver the flexibility and performance required for next-generation Ethernet storage and data transport.
Features
| Fourth-generation improved silicon |
| Five unique models supporting high-speed Ethernet standards from 10GbE to 100GbE |
| High-performance x8 PCIe 3.0 or x16 PCIe 4.0 |
| ATTO360™ Networking |
| Supports up to 100Gb/s throughput |
| RDMA over Converged Ethernet (RoCE) enables industry-leading low-latency and decreases CPU utilization on Linux and Windows |
| End-to-end Quality of Service and congestion control |
| Models support SFP+/RJ45(10GbE), SFP28 (25GbE), QSFP+(40GbE), and QSFP28 (50GbE/100GbE) |
| TCP/UDP/IP hardware based stateless offloads |
| Advanced HW/SW offloads including LRO, LSO, TSO, RSS, and TSS |
| Supports Data Center Bridging; Priority-based Flow Control (PFC), Enhanced Transmission Selection (ETS) and DCB Exchange (DCBX) protocol |
| SR-IOV technology dedicates adapter resources for virtual machines within servers |
| Hardware-based I/O virtualization |
| Advanced Congestion Avoidance |
| Low profile form factor |
| Includes full and half height bracket |
- Product Identifiers -
MPN: FFRM-N4S2-000- Product Specifications -
| Bus Specifications | x8 PCIe 3.0 or x16 PCIe 4.0 |
|---|---|
| Management Tools | ATTO360 Networking ATTOview Time Series Database ATTO Ethernet Suite custom installer |
| Operating System Support | Windows Windows Server® macOS Linux |
| External Connectivity | QSFP28 (50/100GbE) N412 SFP28 (25GbE) N422 and N424 QSFP+ (40GbE) N412 optional support SFP+ (10GbE) N4S2 RJ45 (Base-T) N4T2 2 LED indicators per port |
| Network Standards | IEEE 802.3by (25 Gigabit Ethernet) IEEE 802.3ba (40 Gigabit Ethernet) IEEE 802.3cd (50 Gigabit Ethernet) IEEEE 802.3z (100 Gigabit Ethernet) IEEE 802.3az (Energy Efficient Ethernet) IEEE 802.1p (Priority Encoding) IEEE 802.3ad (Link aggregation) IEEE 802.1qbb (Priority flow control) |
| Operating Temperature | Temperature: 0-55° C Max Junction Temp to 110° C N4T2 - 55C Ambient, 24 LFM with 10G BaseT N4S2 - 55C Ambient, 100 LFM N422 - 55C Ambient, 50 LFM DAC, 150 LFM optics N412 - 55C Ambient, 225 LFM DAC, 420 LFM optics Humidity: 10-90% non-condensing |
| Storage Temperature | Temperature: -40 C to 70° C Humidity: 5-95% non-condensing |
| Agency Approvals | FCC Part 15 Subpart B, Class A EN55022: 2010, Class A EN55024: 2010 |
| Compliance | EN60950-1 EN60825-1 EN60825-2 RoHS |
| Warranty | Three (3) Years |
| ATTO FastFrame | N422 | N424 | N412 | N4S2 | N4T2 |
|---|---|---|---|---|---|
| Max Transfer Rate | 25Gb/s | 25Gb/s | 100Gb/s | 10Gb/s | 10Gb/s |
| Ports | Dual | Quad | Dual | Dual | Dual |
| Bus Characteristics | x8 PCIe 3.0 | x16 PCIe 4.0 | x16 PCIe 4.0 | x8 PCIe 3.0 | x8 PCIe 3.0 |
| Connector | SFP28 | SFP28 | QSFP28 | SFP+ | RJ45 |
| Form Factor | Low Profile | Low Profile | Low Profile | Low Profile | Low Profile |
| OS Support | macOS*/Windows/Linux | macOS/Windows/Linux | macOS/Windows/Linux | macOS*/Windows/Linux | macOS*/Windows/Linux |
| SKU w/Optics | FFRM-N422-000 | FFRM-N424-000 | FFRM-N412-000 | FFRM-N4S2-000 | FFRM-N4T2-000 |
*N422, N4S2, and N4T2 models support macOS in Mac Pro and 3rd-Party Thunderbolt 5 chassis only.
