The Blackmagic Cintel Scanner G3 HDR+ 8/16 is a real time film scanner built for 16mm and 8mm transfer work, scanning Super 16, 16mm, Super 8 and standard 8mm film at up to Ultra HD resolution with up to 3.5 additional stops of HDR captured through an RGB LED grid array light source. Digital servos, a capstan based transport and built in cleaning rollers keep film handling gentle across a run.
Both the 16mm and 8mm HDR gates are included in the box, so the scanner is ready to run either gauge without buying separate gate kits, and Image Mill stabilization is built in to keep scans steady even on shrunken or damaged stock.
A single Thunderbolt 3 cable connects the scanner to a Mac, Windows or Linux workstation at up to 40Gb/s, with a PCI Express interface available for systems without Thunderbolt 3. An HDMI output drives an Ultra HD monitor for focus and alignment, and bi-phase and timecode outputs sync external audio followers.
DaVinci Resolve Studio is included for grading and restoration, with OpenFX tools for dust busting, automatic dirt removal, patch replacement, deflickering and noise reduction built right into the same application the scan lands in.
Highlights
| Includes both 16mm and 8mm HDR gates, ready to scan either gauge out of the box | |
| Up to 3.5 additional stops of HDR from an RGB LED grid array light source | |
| Single cable Thunderbolt 3 connection at up to 40Gb/s | |
| Built in Image Mill stabilization for steady scans of shrunken or damaged film | |
| DaVinci Resolve Studio included for grading and restoration |
- Product Identifiers -
MPN: CINTELSCAN4KG3CAP/816EAN: 9338716010060
- Product Specifications -
Film and Resolution
| Film Gauges | 16mm, Super 16, 8mm, Super 8 |
| Native Sensor Resolution | 4096 x 3072 |
| Effective Resolution | Super 16: 2966 x 1781; Standard 16: 2464 x 1798; Super 8: 1390 x 994; Standard 8: 1172 x 884 |
| Dynamic Range | 12 stops normal scan; up to 3.5 additional stops in HDR scan |
| Run Speed | 1 to 30 fps scanning; shuttle up to 150 fps (16mm) or 200 fps (8mm) |
| Acceleration | 10 to 60 fps per second |
| Film Shrinkage Tolerance | Up to 2 percent guaranteed |
| Reel Capacity | 2000 ft |
Connectivity
| Computer Interface | Thunderbolt 3 (image/audio capture, updates, USB-C charging at 15W/5V); PCI Express 4-lane Gen 2 |
| HDMI Output | 1 x HDMI 1.4, 10-bit 4:2:2, preview only, 3840x2160 or 1920x1080 auto matched to monitor |
| Bi-Phase/Timecode | XLR3 bi-phase at 4.5V DC coupled; timecode at 1.5V DC coupled, 24/25/30 fps |
| Analog Audio In | 2 channel balanced XLR, 10dBV, with sample rate converter |
| AES/EBU Audio In | 1 channel XLR with sample rate converter |
| Options Interface | XLR6 for audio or KeyKode reader accessories |
Transport and Build
| Transport | Rubber capstan |
| Dirt and Scratch Reduction | Diffuse light source plus cleaning rollers |
| Mounting | Desk or wall mount |
| Included Gates | 16mm HDR gate and 8mm HDR gate |
| Included Accessories | 16mm packer kit, DaVinci Resolve Studio dongle |
Power and Environment
| Power | 100 to 240V AC, 200W |
| Operating Temperature | 18 to 28 deg C (64.4 to 82.4 deg F) |
| Relative Humidity | Maximum 65 percent, non condensing |
| Software | Requires Desktop Video; controlled via DaVinci Resolve or the Cintel SDK |
| Operating System | macOS 13.0 Ventura, 14.0 Sequoia or later; also supports Windows and Linux |
| Warranty | 1 year limited manufacturer warranty |
