The Blackmagic ATEM 4 M/E Constellation IP Plus doubles the ATEM 4 M/E Constellation IP to 64 standards converted inputs and 64 outputs over 8 sets of dual redundant 100G Ethernet connections, built for the largest native SMPTE 2110 broadcast facilities that need maximum input count without adding a second switcher frame.
Four M/E rows carry the same 16 ATEM Advanced Keyers, 20 linear and luma keyers, 4 stinger and 4 DVE transition keyers for 28 total layers as the standard IP model, while 2 SuperSource processors add further picture in picture and multi box compositing. SMPTE ST 2022-7 sends every stream as two identical copies across redundant connections, so the switcher keeps running even if one network path drops.
A 132 channel audio mixer roughly doubles the standard model's mixing capacity, with 6 band parametric EQ and full dynamics processing on every channel and Fairlight Live support for surround and immersive mixes over USB. Free ATEM Software Control runs the whole switcher from a computer, with optional ATEM Advanced Panels for hands on control.
Highlights
| 64 standards converted inputs and outputs over 8 sets of redundant 100G Ethernet | |
| Native SMPTE 2110 and SMPTE ST 2022-7 redundancy for all IP broadcast | |
| 4 M/E rows with 16 Advanced Keyers and 28 total layers | |
| 132 channel audio mixer with Fairlight Live surround and immersive mixing |
- Product Identifiers -
MPN: SWATEMSCN2/3ME4/IP/PEAN: 9338716010510
- Product Specifications -
Networking and I/O
| Video Inputs/Outputs | 64 in / 64 out |
| 100G Connections | 8 sets of dual redundant 100G QSFP28 (16 total ports) |
| Channels per 100G Pair | 8 x Ultra HD senders/receivers |
| Standards | SMPTE 2110-20, -21, -30 (Level C audio), -40; SMPTE 2022-7 redundancy |
| Timing | IEEE 1588-2008 (PTP v2), ST 2059-1/-2; NMOS IS-04, IS-05, BCP-002-01, BCP-004-01 |
M/E, Keyers and Effects
| M/E Rows | 4 |
| Upstream Keyers | 16 |
| Downstream Keyers | 4 |
| Advanced Chroma Keyers | 16 |
| Linear/Luma Keyers | 20 |
| Transition Keyers | 4 Stinger, 4 DVE |
| Total Layers | 28 |
| SuperSource | 2 processors |
| Multiview | 4 x 16 patterns, up to 64 views |
| Media Players | 4, with 64 stills and 4 clips |
Audio and Power
| Audio Mixer | 132 channels, 6 band parametric EQ, full dynamics |
| Fairlight Live | Surround and immersive mixing over USB |
| Power Supply | 2 x internal 100-240V AC |
| Power Usage | 390W maximum |
| Rack Size | 3 rack units |
| Software | ATEM Software Control; optional ATEM Advanced Panels |
| Warranty | 1 year limited manufacturer warranty |
