The Blackmagic ATEM 4 M/E Constellation 4K Plus is a 4 RU Ultra HD live production switcher with 80 standards converted 12G-SDI inputs and 48 dedicated 12G-SDI outputs, built for large scale broadcast and live event productions that need a deep bank of sources and outputs in a single frame.
Four M/E rows carry 16 ATEM Advanced Keyers, 20 linear and luma keyers, 4 stinger and 4 DVE transition keyers for 28 total layers, while 2 SuperSource processors add 12 DVEs worth of picture in picture and multi box compositing. Every input has its own standards converter and frame rate converter, so sources of different formats and rates can be mixed freely.
Four MADI outputs break out audio from the first 60 SDI inputs, and 2 MADI inputs add 128 extra mixer channels, with 6 band parametric EQ and full dynamics processing on every channel and Fairlight Live support for surround and immersive mixes over USB. Free ATEM Software Control runs the whole switcher from a computer, with optional ATEM Advanced Panels for hands on control.
Highlights
| 80 standards converted 12G-SDI inputs and 48 dedicated 12G-SDI outputs | |
| 4 M/E rows with 16 Advanced Keyers and 28 total layers | |
| 2 SuperSource processors add 12 DVEs of compositing | |
| MADI audio I/O plus Fairlight Live for surround and immersive mixing |
- Product Identifiers -
MPN: SWATEMSCN2/2ME4/4K/PEAN: 9338716009972
- Product Specifications -
Inputs and Outputs
| Video Inputs | 80 x 12G-SDI, standards converted with re-sync |
| Video Outputs | 52 total; 48 x 12G-SDI aux outputs |
| Down-Converted Program Outputs | 8 |
| Multiview Outputs | 4 dedicated, plus up to 48 extra routable outputs |
| Webcam Output | 1 x USB-C (720p or 1080p) |
M/E, Keyers and Effects
| M/E Rows | 4 |
| Upstream Keyers | 16 |
| Downstream Keyers | 4 |
| Advanced Chroma Keyers | 16 |
| Linear/Luma Keyers | 20 |
| Transition Keyers | 4 Stinger, 4 DVE |
| Total Layers | 28 |
| DVEs | 4 |
| SuperSource | 2 processors |
Audio
| Mixer | 6 band parametric EQ with expander, gate, compressor and limiter dynamics |
| Analog Audio | 2 x balanced 1/4 inch in, 2 x balanced 1/4 inch out |
| MADI | 2 x 64 channel MADI in, 4 x 64 channel MADI out |
| Talkback | 5 pin XLR in and out |
| Embedded SDI Audio | 8 channels per input, 16 channels per output |
| Fairlight Live | Surround and immersive mixing over USB |
Power and Physical
| Power Supply | 2 x internal 100-240V AC |
| Power Usage | 400W maximum |
| Rack Size | 4 rack units |
| Software | ATEM Software Control; optional ATEM Advanced Panels |
| Warranty | 1 year limited manufacturer warranty |
