AJA HA5-Fiber HDMI to 3G-SDI over Fiber Video and Audio Mini Converter

SKU:
AJA-HA5-FIBER
AJA HA5-Fiber HDMI to 3G-SDI over Fiber Video and Audio Mini Converter - Image 1
Condition:
New
Brand Name:
UPC:
892448000687
Product highlights
-
HDMI to 3G-SDI over fiber; Supports single mode 1310 nm fiber optic cable with ST transmitter
-
Full HDMI input support including embedded audio
-
Additional 2-Channel RCA style analog audio (-10dBu nominal) input
-
HDMI cable included
-
5-Year Manufacturers Warranty
Product Family
Mini Converters
Availability:
In Stock - usually ships next business day
Your Price: $695.00 $625.50
(You save $69.50)

Ask an expert

Not sure what you need or if you're looking at the right product?

(888) 542-8941

The AJA HA5-Fiber converts a HDMI input to 3G-SDI over single mode 1310 nm fiber optic cable (ST-style fiber connector) for transporting HDMI sources over fiber. The small form factor enables this Mini Converter to easily fit onto the back of a camera or neatly behind an equipment rack. Embedded 8-Channel audio is supported in the fiber output allowing a convenient single cable audio/video connection up to 10km. The HA5-Fiber also provides 2-Channel RCA style audio inputs for a stereo audio input when needed. 5-year manufacturer's warranty.


- Product Identifiers -

MPN: HA5-FIBER

- Product Specifications -

Technical Specifications

  • Input Formats
    • (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60K
    • (HD) 1080i 50, 59.94, 60
    • (HD) 720p 50, 59.94, 60
    • (SD) 625i
    • (SD) 625p
    • (SD) 576p
    • (SD) 525i
    • (SD) 525p
    • (SD) 480p

      NOTE: HDCP content not supported

  • Output Formats
    • (HD) 1080i 25, 29.97, 30
    • (HD) 1080p 23.98, 24, 25, 29.97, 30
    • (HD) 1080p 50, 59.94, 60 - SMPTE 425-1 Level A mapping structure 1 (1920 x 1080 4:2:2 10-bit YCbCr)
    • (HD) 720p 50, 59.94, 60
    • (SD) 625i 25
    • (SD) 525i 29.97

  • Video Input
    • HDMI with embedded audio, up to 8-Channels

  • Video Output
    • Single mode optical fiber, ST connector supporting SMPTE-259/292/424 3G/HD/SD-SDI

  • Audio Input
    • 2-Channel RCA style analog audio (-10dBu nominal)

  • Audio Output
    • SDI embedded audio

  • Optical Output
    • Wavelength: 1310nm
    • Output Power: -2dBm typical

  • Size (w x d x h)
    • 4.4" x 2.4" x 1.0" (112mm x 61mm x 25mm)

  • Weight
    • 0.3 lb (0.2 kg)

  • Power
    • Uses AJA power supply model DWP-U-R1, included with purchase
    • 100-240V, 50/60 Hz universal input
    • +5V DC regulated, 4.5 watts

  • Environment
    • Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
    • Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140 degrees F)
    • Operating Relative Humidity: 10-90% noncondensing
    • Operating Altitude: <3,000 meters (<10,000 feet)
