Product image one of Blackmagic Design Teranex Mini - Analog to SDI 12G

Blackmagic Design Teranex Mini - Analog to SDI 12G

Your Price: $545.00
SKU:
BMD-CONVNTRM-BB-ANSDI

Availability:
In Stock - usually ships next business day

Product highlights
-
Convert from analog video to 12G-SDI. Convert incoming analog video signals to SD, HD, 6G and 12G-SDI.
-
Advanced 12G-SDI connections for working with SD, HD and Ultra HD up to 2160p60.
-
Professional XLR audio connections with low noise floor when used in analog mode.
-
Built in power 90V - 240V international power supply for use anywhere in the world.
-
Unique crossflow cooling with variable speed fans for quiet, reliable operation. Optional Smart Panel and Rack Shelf sold separately.
Product Family
Teranex
  • - Convert from analog video to 12G-SDI. Convert incoming analog video signals to SD, HD, 6G and 12G-SDI.
  • - Advanced 12G-SDI connections for working with SD, HD and Ultra HD up to 2160p60.
  • - Professional XLR audio connections with low noise floor when used in analog mode.
  • - Built in power 90V - 240V international power supply for use anywhere in the world.
  • - Unique crossflow cooling with variable speed fans for quiet, reliable operation. Optional Smart Panel and Rack Shelf sold separately.
  • Product Family Teranex
Availability:
In Stock - usually ships next business day
Free Shipping on Orders over $250
Pay Per Month

ASK AN EXPERT

Not Sure What You Need Or If You're Looking At The Right Product?

Convert from analog video to 12G-SDI. Convert incoming analog video signals to SD, HD, 6G and 12G-SDI. Ideal for converting your analog devices such as Betacam SP, VHS, set top boxes, gaming consoles and HDV cameras to incredible quality SD/HD/Ultra HD SDI video up to 2160p60.


- Product Identifiers -

MPN: CONVNTRM/BB/ANSDI
EAN: 9338716003277

- In The Box -

  • Teranex Mini - Analog to SDI 12G
  • SD card with software and manual


- Product Specifications -

Connections

  • SDI Video Outputs
    2 x 12G-SDI outputs.

  • Analog Video Inputs
    Composite, Y/C or Component.

  • Analog Audio Inputs
    2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for timecode input.

  • Digital Audio Inputs
    4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for timecode input.

  • Multi Rate Support
    SDI output switchable between HD for composite and S-Video and Ultra HD for component HD.

  • Updates and Configuration
    USB or Ethernet.

  • Reclocking
    Yes

Standards

  • SDI Video Standards
    • 525i59.94 NTSC, 625i50 PAL
    • 720p50, 720p59.94, 720p60
    • 2160p25, 2160p29.97, 2160p50, 2160p59.94
    • 1080i50, 1080i59.94, 1080i60

  • SDI Compliance
    SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10

  • SDI Video Rates
    SDI video connections are switchable between standard definition and high definition.

  • SDI Video Sampling
    4:2:2 and 4:4:4.

  • SDI Audio Sampling
    Television standard sample rate of 48 kHz and 24-bit.

  • SDI Color Precision
    YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.

  • SDI Color Space
    REC 601, REC 709

  • Analog Video Standards
    525i59.94 NTSC, 625i50 PAL

  • Analog Color Space
    REC 601, REC 709

  • Analog Color Precision
    4:2:2

Software

  • Software Control
    Mac™ and Windows™ software upgrade via USB and Ethernet.

  • Internal Software Upgrade
    Via included updater application.

Operating Systems

  • Mac 10.12 Sierra, Mac 10.13 High Sierra or later.
  • Windows 8.1 or Windows 10.

Settings Control

  • Basic Settings Control
    Mini Switches, USB and Ethernet via free software utility.

  • Optional Front Panel Control
    Front mounted Smart Panel with LCD, rotary knob and six settings buttons.

Power Requirements

  • Power Supply
    1 x built in international AC power supply with IEC C14 inlet. IEC Power cable required. 90 - 240V AC Input.

  • Power Over Ethernet
    Can be powered via 48V DC using PoE+ (power over ethernet).

  • Power Consumption
    16 Watts

  • Operational Voltage Range
    90 - 240V AC

Physical Specifications

  • Dimensions
    5.51in x 6.69in x 1.75in

  • Weight
    1.41lbs

Environmental Specifications

  • Operating Temperature
    0° to 40°C (32° to 104°F)

  • Storage Temperature
    -20° to 60°C (-4° to 140°F)

  • Relative Humidity
    0% to 90% non-condensing
