The Blackmagic Streaming Decoder 4K is a one third rack width hardware decoder that receives an RTMP or SRT stream from a Streaming Encoder, ATEM switcher or compatible camera and converts it back to 12G-SDI and HDMI outputs, built for distributing a live stream to displays or production equipment at a remote venue.
The decoder outputs video on 12G-SDI, a dedicated SDI reference loop and HDMI 2.0 up to DCI 4K, with built in frame rate and format conversion so an incoming stream matches whatever downstream equipment expects. A talkback and program audio input lets on site crew hear cues from the originating venue, and a USB-C port doubles as an Ultra HD webcam output.
Highlights
| Decodes RTMP or SRT streams back to 12G-SDI and HDMI outputs | |
| Built in frame rate and format conversion to match downstream equipment | |
| Supports remote camera control, color correction and tally from the source | |
| USB-C webcam output up to 2160p60 |
- Product Identifiers -
MPN: BDLKWEB/J/DES4KEAN: 9338716010053
- Product Specifications -
Video I/O
| SDI In | 1 x SDI reference input, 1.5G/3G/6G/12G |
| SDI Out | 1 x 12G-SDI video out, 1 x SDI reference out |
| HDMI Out | 1 x HDMI 2.0 out, up to DCI 4K |
| Conversion | User configurable frame rate and format conversion on the SDI and HDMI outputs |
Decoding
| Input Protocols | RTMP and SRT, from Streaming Encoder, ATEM switchers or compatible cameras |
| Codecs Received | H.264 over RTMP; H.264 and H.265 over SRT |
| HDR | HLG and ST2084/PQ metadata, 300 to 4000 nits |
| Webcam Output | 1 x USB-C, up to 2160p60 |
Audio and Control
| SDI Audio | 16 channels on reference in, reference out and 12G out |
| HDMI Audio | 8 channels out |
| Talkback/Program | 2 channel talkback in, 2 channel program in |
| Remote Control | Remote camera control, color corrector, tally and talkback over the network link |
| Ethernet | 10/100/1000BASE-T for configuration and updates |
Power and Physical
| Power | Internal 100-240V AC; 12V DC 4-pin XLR |
| Form Factor | One third rack width, 1 rack unit high |
| Warranty | 3 year limited manufacturer warranty |
