The Blackmagic PYXIS 12K EF is a full-frame digital film camera built around a 12,288 x 8,040 RGBW sensor with 16 stops of dynamic range, fitted with a fixed, locking EF mount for direct use with the large library of Canon EF-compatible photo and cine lenses already in a rental house or production kit. An iris wheel, touchscreen slider and an instant auto-iris button give manual and automatic exposure control on compatible lenses.
Open gate 12K capture runs at up to 40 fps, with windowed 9K, 8K and 4K modes available at progressively higher frame rates up to 112 fps for slow motion work. Every frame is recorded as 12-bit Blackmagic RAW across dual CFexpress Type B card slots, with H.264 proxies generated in real time for editorial and a pre-record buffer that can hold up to 10 minutes of footage before the shot is called.
A 4 inch 1500 nit HDR touchscreen handles on-camera monitoring and menu control, while a 12G-SDI output feeds an external monitor or recorder in Ultra HD. Built-in RTMP and SRT streaming, 10G Ethernet and Blackmagic Cloud connectivity let footage move from set to a DaVinci Resolve project with proxies syncing automatically, and DaVinci Resolve Studio is included with every camera.
The CNC-machined aerospace aluminum body includes multiple 1/4 inch and 3/8 inch mounting points, a standard side plate and an SSD plate in the box, and support for an optional Rosette Plate, PYXIS Monitor, URSA Cine EVF and Pro Handle for run and gun shooting.
Features
| Full-frame 12K RGBW sensor with 16 stops of dynamic range | |
| Records 12-bit Blackmagic RAW with simultaneous H.264 proxies | |
| Dual CFexpress Type B slots plus 10Gb/s USB-C for external media | |
| 10G Ethernet for Blackmagic Cloud upload and REST API camera control | |
| DaVinci Resolve Studio included for a complete end to end workflow |
Mount and Lens Control
| Mount | Fixed, locking EF mount compatible with Canon EF photo and cine lenses |
| Lens Control | Iris and focus on supported lenses |
| Metadata | Camera settings, motion sensor data, slate data; 3D LUT embedded in Blackmagic RAW |
Sensor and Image
| Sensor | Full-frame 36 x 24 mm RGBW, 12,288 x 8,040 photosites, built-in optical low-pass filter |
| Effective Sensor Size | 35.64 x 23.32 mm (large format) |
| Pixel Pitch | 2.9 microns |
| Dynamic Range | 16 stops |
| Native ISO | 800 (range 200 to 3200) |
| Color Science | Blackmagic Generation 5 color science with 12-bit gamma curve |
Recording and Media
| Codec | Blackmagic RAW, constant bitrate (3:1 to 18:1) and constant quality (Q0, Q1, Q3, Q5) |
| Proxy Recording | Simultaneous H.264 1920 x 1080 8-bit 4:2:0 proxies |
| Top Resolution | 12,288 x 8,040 open gate 12K at up to 40 fps; scales to 9K, 8K and 4K at higher frame rates |
| Media Slots | 2 x CFexpress Type B, hot-swappable |
| External Media | 1 x 10 Gb/s USB-C port for external SSD or flash drive recording |
| File Systems | ExFAT (Windows/Mac) or HFS+ (Mac) |
| Pre-Record Buffer | Selectable from 5 seconds up to 10 minutes |
Connectivity
| Video Output | 1 x 12G-SDI up to 2160p60 |
| Audio Input | 1 x mini XLR with 48V phantom power, 1 x 3.5mm stereo input |
| Audio Output | 3.5mm headphone jack; built-in stereo microphone and mono speaker |
| Reference In | Tri-Sync/Black Burst and timecode |
| Computer Interface | USB-C for external recording, PTP camera control and software updates |
| Ethernet | 1 x 10Gb/s RJ-45 (10/100/1000/10G BASE-T) for Blackmagic Cloud and REST API control |
Monitoring and Control
| Built-In Screen | 4 inch 1920 x 1080 capacitive HDR touchscreen, 1500 nits |
| Remote Control | Blackmagic Zoom and Focus Demand, iPad, Bluetooth, USB PTP, Camera Control REST API |
| Live Streaming | Built-in RTMP and SRT, plus 4G/5G streaming via phone over USB-C |
| Cloud Workflow | Live proxy sync to DaVinci Resolve projects through Blackmagic Cloud |
| Optional Monitoring | PYXIS Monitor, URSA Cine EVF and Pro Handle with integrated OLED viewfinder |
Power and Physical
| Power Input | Locking 12-18V DC, external 18V 90W supply included |
| Battery | BP-U series batteries, up to 3+ hours on the highest-capacity battery |
| Body | CNC-machined aerospace aluminum with multiple 1/4 inch and 3/8 inch mount points |
| Included Software | DaVinci Resolve Studio with activation key, Blackmagic Camera Setup, Blackmagic RAW tools |
| Warranty | 1 year limited manufacturer warranty |
- Product Identifiers -
MPN: CINECAMCPYXN12LFEFEAN: 9338716009934
