Product image one of Salrayworks K-M20 1/2.8'' Exmor R CMOS Sensor PTZ Camera (Optical Zoom: 20x / Digital Zoom: 12x, White)

Salrayworks K-M20 1/2.8'' Exmor R CMOS Sensor PTZ Camera (Optical Zoom: 20x / Digital Zoom: 12x, White)

Limited Availability - contact us for details
Your Price: $1,368.00
SKU:
SRW-K-M20-W

Condition:
New

Availability:
Limited Availability - contact us for details

UPC:
706249186085
Product highlights
-
20x optical zoom; 12x digital zoom
-
Interface: 3G-SDI, HDMI, CVBS
-

-

-

  • - 20x optical zoom; 12x digital zoom
  • - Interface: 3G-SDI, HDMI, CVBS
  • -
  • -
  • -
Availability:
Limited Availability - contact us for details
Free Shipping on Orders over $250
Pay Per Month

ASK AN EXPERT

Not Sure What You Need Or If You're Looking At The Right Product?

Full HD image quality with 60fps frame rate
1920x1080/60p

See every presenter or conference participant more clearly. The 1/3-type CMOS image sensor captures smooth, crisply detailed, Full HD (1920 x 1080 60p) images with extremely low noise – even in low light conditions where other cameras struggle. High frame rate (60fps) operation ensures smoother, more fluid reproduction of moving subjects.

Powerful 20x/30x optical zoom

The 20x/30x optical zoom range is complemented by 12x digital zoom for frame-filling close-ups with every detail seen clearly. Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings.

Multi-format output video
SD/HD/3G-SDI, HDMI,CVBS

The KM/KS Model series can simultaneously output 1080/60p baseband video through 3G-SDI, HDMI stream.

Versatile connectivity options

VISCA, PELCO-D/P / RS-232C,422,485 and Support for RS-232C,422,485 communication allows easy connection with a wide range of peripheral products. The camera can also be controlled via VISCA protocols over a standard VISCA, PELCO-D/P.

Enhanced PTZ operation ±172°/ 220°

The powerful direct drive motor assures quiet, rapid movement to the target position over a wide pan/tilt angle range. PTZ synchronization ensures smoothly co-ordinated camera movements, while Pan/Tilt speed can be set to 'Slow' for smooth, professional looking transitions. A sequence of camera positions can be stored to memory and recalled as a preset 'trace'.

Wide 57.4-degree viewing angle

See every meeting participant in a boardroom with a wide 65-degree horizontal viewing angle.

256 programmable presets

Store and instantly recall up to 256 camera positions via KM/KS Model PTZ Controller C series from specific controller.

Suitable for desktop or ceiling mounting

Image flip gives extra operating flexibility, allowing the camera to be sited on a boardroom table-top or ceiling mounted while maintaining proper image orientation.


- Product Identifiers -

MPN: K-M20-W
UPC: 706249186085

- Product Specifications -

Camera

  • Module: (12x) 1/19" Exmor CMOS, (20x) 1/2.8" Exmor R CMOS
  • Valid Pixels: 1920[H]x1080[V] (Approximately 2.1 million pixels)
  • Video output format: 1920x1080p60, 1920x1080i60, 1920x1080p30, 1280x720p60, 1280x720p30, 720x576i50(CVBS only), 1920x1080p59.94, 1920x1080i59.94, 1280x720p59.94, 1920x1080p50, 1920x1080i50, 1920x1080p25, 1280x720p50, 1280x720p25
  • Video output: HD/3G-SDI, HDMI, DVI, CVBS
  • Zoom Scale: Optical zoom: 12/20x, Digital zoom: 12x
  • Lens: 12x Zoom Lens [f=4.7~56.4 mm F1.6~F3.5] / 20x Zoom Lens [f=4.7~94 mm F1.6~F4.7]
  • Viewing Angle: 57.4°(W), 3.2°(T)
  • Minimum Luminance
    • 0.2lx (Day)
    • 0.1lx (Night)
    • 0.005lx (DSS on)

Camera function

  • Day&Night: AGC, TDN(ICR)
  • Focus: Semiauto / Auto / Manual
  • Image Flip: On / Off
  • Zoom Speed: 0~7
  • Focus Near Limit: 30cm / 1m / 1.5m / 2m / 3m / 5m / 10m
  • AF Sensitivity: Normal / Low
  • Defog Mode: Off / Low / Mid / High
  • High Sensitivity: Off / On
  • Noise Reduction: Off / 1~5
  • Aperture: 10, 0~15
  • White Balance: Auto / Indoor / Outdoor / One Push / ATW / Manual / Outdoor Auto / Sodium Auto / Sodium / Sodium Out Auto
  • Program AE: Full Auto / Bright / Shutter Pri / Iris Pri / Manual
  • WDR: Off / On / VE
  • BLC: On / Off

Pan / Tilt

  • Moving Angle: Pan: -172° ~ 172°(Non-Endless), Tilt: total 220°(-20° ~ 0° ~ 180° ~ -160°)
  • Moving Speed: Manual: 0.002°/sec ~ 180°/sec (Interlocked with the Zoom Scale), Preset: 300°/sec, Swing: 1°/sec ~ 180°/sec
  • Preset setup: 256 Presets[VISCA], 255 Presets (Label setup, each display setup)[PELCO]
  • Swing setup: 8 swings
  • Pattern setup: 8 Patterns
  • Group setup: 8 Groups (20 motions/Group)
  • Other functions: Smart-Flip, Home Position Set, Auto Parking, Power Up Action etc.

General

  • Cam ID: PELCO: 1~14, VISCA: 1~14 setting
  • Communication: RS-422/485, RS-232C, IR Remote
  • Protocol: PELCO-D/P, VISCA
  • OSD: Menu, Position, etc.
  • Power: DC 12V ± 10% (Max 1A)
  • Dimension: 166 x 183 x 175 mm(W x D x H)
  • Weight: Approximately 1.95kg
  • Operating temperature: 0°C ~ 40°C(32°F~104°F)
